4-channel analog input/ 2-channel analog output, full-channel support current/voltage type
Model no
EM AM06Article No
E 288-3AM06-0AA1Description
4-channel analog input/ 2-channel analog output, full-channel support current/voltage typeDimensions WxHxD（mm）
47×100×81mm| specification parameters | model no |
em am06 |
|---|---|---|
| article no | e 288-3am06-0aa1 | |
| description | 4-channel analog input/ 2-channel analog output, full-channel support current/voltage type | |
| conventional norm |
dimensions wxhxd（mm） |
47×100×81mm |
| power consumption | 2w | |
| current consumption(sm bus) | 90ma | |
| current consumption(24v dc) | 60ma | |
| analog input |
number of inputs |
4 |
| input type | voltage or current (differential): 2 can be selected as a group range | |
| input range | ||
| electric current | 0~20ma | |
| supply voltage | ±2.5v，±5v，±10v | |
| resolution | ||
| voltage mode | 12 bits + symbol bits | |
| current mode | 12 bits | |
| precision | ||
| .voltage mode | ±0.2%/±0.3% full range | |
| .current mode | ±0.2%/±0.3% full range | |
| analog to digital conversion time | 625 µs（400hz inhibited） |
