Analog output module AQ2 x 14 bits, Max. Voltage Resistance ±60V
Model no
SM1232 AQ2 x 14 BitsArticle No
H7 232-4HB32-0XB0Description
Analog output module AQ2 x 14 bitsDimensions WxHxD（mm）
45x100x75mm| Specification parameters | Model no | SM1232 AQ2 x 14 Bits | Article No | H7 232-4HB32-0XB0 | Description | analog output module AQ2 x 14 bits |
|---|---|---|
| Conventional norm | Dimensions WxHxD（mm） | 45x100x75mm | Power Consumption | 1.5W | Current Consumption(SM bus) | 80mA | Current Consumption(24V DC) | 45mA（no load） |
| Analog output | Number of Outputs | 2 | Output Type | Voltage or current | Output Range | Current Output | 0－20mA or 4－20mA | Voltage Output | ±10V | Data Word Format | Voltage | -27648-27648 | Current | 0-27648 | Resolution | Voltage Mode | 14 bits | Current Mode | 13 bits | Max. Voltage Resistance | ±60V | Isolation (field side and logic side) | 500VAC | Precision(25℃/0-55℃) | full range ±0.3% /±0.6% | Stability Time | Voltage: 300μS(R), 750μS(1 uF); Current: 600μS(1 mH), 2 ms(10 mH) | Load Impedance | Voltage: ≥ 1000 Ω; Current: ≤ 600 Ω | Output Status in STOP Mode | previous value or replacement value (default is 0) | Diagnosis | Overflow/underflow | Support | Voltage Mode: short circuit to ground | Support | Current Mode: Circuit break mode | Support |
